Housing and frame: die-cast aluminum.
Paintwork: thermosetting polyester powder, prior degreasing, and phosphochromatizing process that will ensure an extremely high resistance to chemical and atmospheric agents.
LED: Samsung LH351C, CRI>70, CCT 4000K.
Expected lifetime: 157.000h L80 B10 @ta25, 133.000h L80 B10 @ta50.
Goniometer: one-side for precise, simple, and quickly pointing.
Power supply: 100-305V 50/60Hz with electronic ballast, 6/10kV surge protection, inrush current (cold start) 85A for single module, over-temperature protection, overcharging protection, shortcircuit protection, low ripple.
Bracket: 4 mm slotted and thick-shaped steel. 120° product adjustment. 120° single-module adjustment.
Available versions:
AS: shockproof cluster in PMMA anti UV UL94, an asymmetrical lens with vertex at 55°;
15°: shockproof cluster in PMMA anti UV UL94, curved rotosym-metrical optic, and beam 15°;
24°: shockproof cluster in PMMA anti UV UL94, curved rotosym-metrical optic, and beam 24°;
40°: shockproof cluster in PMMA anti UV UL94, curved rotosym-metrical optic and beam 40°.
