Die-cast body and flange manufactured in aluminium alloy with very low copper
content. External power supply with 12/24V DC constant-current transformer,
to be wired in parallel. Subjected to galvanic anodizing treatment divided into
distinct phases: mechanical satin finishing, surface degreasing, anodic
oxidation and final sealing. The product is painted following a continuous two
step paint process (epoxy-based primer + polyester-based colour finish), which
allows to generate a single thick protective coating which then generates
aprotective barrier against atmospheric agents and UV rays. Before fixing the
diffuser on the Platek products a Pre-treatment using an atmospheric pressure
plasma process is carried out on the surface. The process activates the ionic
load on the surface exactly where it is needed, thus promoting the best silicone
grip possible and removing any residual release of agents for a longer lasting
seal. The next steps are the coating of silicone and the assembly of the diffuser
on the lighting fixture, with an automated process to guarantee the perfect
sealing of the lamp. Nylon outer housing to be ordered separately.
