PROTECTION DEGREE IP66 / IMPACT PROTECTION IK08 / 10
Material: Module and body made of thermo painted injected aluminum and steel.
Optics: LED modules include 110º, 50º, 41º, 32º, 21º, and asymmetric 2 sides optics. Includes waterproof methacrylate (PMMA) with UV protection.
Supply: Driver with IP67 included for all models. Optionally supplied with 1-10V dimmable driver (Ref.- DR), Dali dimmable driver (Ref.- DRD), or programmable dimmable driver (Ref.- DRPR) and Regulation at the
heady (DRC).
Lamps: Module composed of OSRAM LED with a total power of 185w, 370w, 555w, and 740w. Available in 3000K, 4000K, and 5000K. CRI>80.
Life span: Estimated Average Life span 60.000 hours.
Protections: The PCB incorporates safety diodes to protect and guarantee its perfect functioning.
Installation: Directly hung up on ceiling by a suspension kit (Screw and suspension not included). Includes quick connector of 3 or 5 poles IP66.
Ambient temp.: -20ºC a 40ºC.
Colors: Luminaire in gray. Opal diffuser closure. It can be supplied in other RAL colors by request.
